Deploy Your Machine Learning Model as a REST API

Deployment of a machine learning model might sound intimidating to beginners, or even to those ones with some experience. That’s why I decided to spend an entire post talking about it.

Dario Radečić

Nov 13 · 5 min read

Photo by Franck V. on Unsplash

After reading the article you will be able to deploy machine learning models and make predictions from any programming language you want. That’s right, you can stick to Python, or you could make predictions directly inside your Android app via Java or Kotlin. Also, you could use the model directly in your web application — the options are endless. For simplicity's sake, I will use Postman.

I, however, won’t explain how to put the model on a live server, because the options are endless and it’s a possibly good idea for another post. The model will be running on your localhost, so no, you won’t be able to access it from a different network (but feel free to google how to deploy models to AWS or something like that).

I’ve gone ahead and made the following directory structure:

ML-Deploy

• model / Train.py
• app.py

Now if you have your Python installed through Anaconda, then you probably already have all the libraries pre-installed, except for Flask. So fire up the terminal and execute the following:

pip install Flask
pip install Flask-RESTful

That went well? Good. Let’s dive into some good stuff now.

---

Making a Basic Prediction Script

If you are following along with the directory structure, you should open up the model/Train.py file now. The goal is to load in the Iris dataset and use a simple Decision Tree Classifier to train the model. I will use joblib library to save the model once the training is complete, and I’ll also report the accuracy score back to the user.

Nothing complex here, as machine learning isn’t the point of the article, only the model deployment. Here’s the whole script:

from sklearn import datasets
from sklearn.tree import DecisionTreeClassifier
from sklearn.model_selection import train_test_split
from sklearn.metrics import accuracy_score
from sklearn.externals import joblib


def train_model():
    iris_df = datasets.load_iris()

    x = iris_df.data
    y = iris_df.target

    X_train, X_test, y_train, y_test = train_test_split(x, y, test_size=0.25)
    dt = DecisionTreeClassifier().fit(X_train, y_train)
    preds = dt.predict(X_test)

    accuracy = accuracy_score(y_test, preds)
    joblib.dump(dt, 'iris-model.model')
    print('Model Training Finished.\n\tAccuracy obtained: {}'.format(accuracy))

---

Deploying

Now you’re ready to open the app.py file and do some imports. You’ll need the os module, a couple of things from Flask and Flask-RESTful, the model training script created 10 seconds ago, and the joblib to load in the trained model:

import os
from flask import Flask, jsonify, request
from flask_restful import Api, Resource
from model.Train import train_model
from sklearn.externals import joblib

Now you should make an instance of Flask and Api from Flask-RESTful. Nothing complex:

app = Flask(__name__)
api = Api(app)

The next thing to do is to check whether the model is already trained or not. In the Train.py you’ve declared that the model will be saved in the file iris-model.model, and if that file doesn’t exist, the model should be trained first. Once trained, you can load it in via joblib:

if not os.path.isfile('iris-model.model'):
    train_model()

model = joblib.load('iris-model.model')

Now you’ll need to declare a class for making predictions. Flask-RESTful uses this coding convention, so your class will need to inherit from the Flask-RESTful Resource module. Inside the class, you can declare get(), post(), or any other method for handling data.

We’ll use post(), so the data isn’t passed directly through the URL. You’ll need to fetch attributes from the user input (prediction is made based on attribute value the user has entered). Then, you can call .predict() function of the loaded model. Just because the target variable of this dataset is in the form (0, 1, 2) instead of (‘Iris-setosa’, ‘Iris-versicolor’, ‘Iris-virginica’), you’ll also want to address that. Finally, you can return JSON representation of the prediction:

class MakePrediction(Resource):
    @staticmethod
    def post():
        posted_data = request.get_json()
        sepal_length = posted_data['sepal_length']
        sepal_width = posted_data['sepal_width']
        petal_length = posted_data['petal_length']
        petal_width = posted_data['petal_width']

        prediction = model.predict([[sepal_length, sepal_width, petal_length, petal_width]])[0]
        if prediction == 0:
            predicted_class = 'Iris-setosa'
        elif prediction == 1:
            predicted_class = 'Iris-versicolor'
        else:
            predicted_class = 'Iris-virginica'

        return jsonify({
            'Prediction': predicted_class
        })

We’re almost there, so hang in tight! You’ll also need to declare a route, the part of URL which will be used to handle requests:

api.add_resource(MakePrediction, '/predict')

And the final thing is to tell Python to run the app in debug mode:

if __name__ == '__main__':
    app.run(debug=True)

And that’s it. You’re ready to launch the model and make predictions, either through Postman or some other tool.

Just in case you missed something, here’s the entire app.py file:

import os
from flask import Flask, jsonify, request
from flask_restful import Api, Resource
from model.Train import train_model
from sklearn.externals import joblib

app = Flask(__name__)
api = Api(app)

if not os.path.isfile('iris-model.model'):
    train_model()

model = joblib.load('iris-model.model')


class MakePrediction(Resource):
    @staticmethod
    def post():
        posted_data = request.get_json()
        sepal_length = posted_data['sepal_length']
        sepal_width = posted_data['sepal_width']
        petal_length = posted_data['petal_length']
        petal_width = posted_data['petal_width']

        prediction = model.predict([[sepal_length, sepal_width, petal_length, petal_width]])[0]
        if prediction == 0:
            predicted_class = 'Iris-setosa'
        elif prediction == 1:
            predicted_class = 'Iris-versicolor'
        else:
            predicted_class = 'Iris-virginica'

        return jsonify({
            'Prediction': predicted_class
        })


api.add_resource(MakePrediction, '/predict')


if __name__ == '__main__':
    app.run(debug=True)

Okay, are you ready?

Great. Navigate to the root directory (where app.py is located), fire up the terminal and execute the following:

python app.py

After a second or so you’ll get an output showing you the app is running on the localhost.

Now I will open Postman and do the following:

• Change the method to POST
• Enter localhost:5000/predict as the URL
• Inside the Body tab choose JSON
• Enter some JSON for prediction

You can then hit Send:

And voila! Almost instantly you’ll get the prediction back from your model.

---

The Final Words

I hope you’ve managed to get through this article. You should be good to go if you just copy-pasted everything, provided that you have all the necessary libraries installed.

I would strongly advise utilizing this newly acquired knowledge on your own datasets, and your own business problems. It comes in handy if you’re coding the app in some other language than Python, and are using Python just for data and machine learning related stuff.

Thanks for reading, take care.
